Well buckets can be made from PVC pipe and some fittings available at nearly any hardware store. (The only hard-to-find item is the foot valve.) Use a 4 or 5 ft. Length of 3-inch diameter white PVC pipe if your well has a 4″ casing, or 4″ diameter pipe if your well has a 6″ casing. Assembling the Bucket.
Jim –
Do you have a diagram or plans for a well torpedo? In case I have the term wrong, a PVC tube with a flapper valve at the bottom that when sent down the well shaft hits the water, the tube fills/sinks, when you pull on the rope the flapper valve closes sealing in the water for you to pull up the well shaft. I have the well. What I need is the way to install the flapper valve. Thanks, – DAB
- For 1.12 some mods that supplied lots of fruits were harvestcraft, cuisine, terraqueous, etc; for 1.14/1.15 there is the new pam's crops/fruit-trees as well as mods like simplefarming and citrus fruit trees (NOTE: you might need a datapack to integrate for 1.14/1.15).
- In the case of simply dropping a well bucket as the OP recommends, the top level of your water reservoir probably isn't nearly so deep that a bucket and rope wouldn't be reasonably feasible. And, in answer to your question, YES, you'll have to take the internal pipe out of the casing to lower a well bucket.
JWR Replies: For any readers that aren’t familiar with them, narrow shaft well buckets–also sometimes called “bullet buckets” or “torpedo buckets” are designed for manually drawing water from modern modern small diameter wells that are more than 20 feet deep. Shallow wells (less than 20 foot depth) are much more efficiently accessed with a hand pump, such as a traditional pitcher-type cistern pump (available from Lehmans.com) or this home-fabricated PVC design by Keith Hendricks, shown at the PermaPak web site. Deeper wells require a sucker-rod actuated pump.
Have a deep well but you can’t afford a manual pump or you don’t foresee anything but short term emergency need to draw water? A bucket will do. The following method works, but you will first have to pull the pump, wiring and its draw pipe before you can use an emergency bucket. Most modern wells have 4-inch or 6-inch diameter casings. Well buckets can be made from PVC pipe and some fittings available at nearly any hardware store. (The only hard-to-find item is the foot valve.) Use a 4 or 5 ft. length of 3-inch diameter white PVC pipe if your well has a 4″ casing, or 4″ diameter pipe if your well has a 6″ casing.
Assembling the Bucket:
For the top cap, drill a hole in the center and insert a threaded eye-bolt with lock washer and nut to hold the lifting/lowering rope. Use PVC cement to attach the pipe cap. Be sure to use sturdy nylon rope. (Recovering a bucket if the rope breaks would be problematic, to say the least.) In the bottom cap, drill a centered hole and install a “foot” valve. This will be open when floating and allow water in to the bucket. The valve will automatically close when the bucket is pulled up. Foot valves (also called “check valves”) are available in PVC construction, as well as brass and cast iron. Depending on the type of valve you buy, you will probably have to screw a threaded pipe adapter (male-to-male short coupling) to into the top of the valve and then glue it into the appropriate size hole that you have drilled into the end cap. Needless to say, you need to be sure that the valve’s “flapper” is oriented in the right direction before you attach it to the bottom cap. You need the bucket valve to hold rather that release water when the bucket is raised!
OBTW, for anyone that would rather buy a commercially-made well bucket, they are available from Ready Made Resources (search on “Well Bucket”), and from Lehmans.com (search on “Galvanized well bucket”.)
Description
Better With Mods Well Bucket Minecraft
The Living Water Well Bucket offers a simple, effective and economical way to get water out of your drilled well. Well buckets are one of the least expensive backups for your water system, providing you a ready source of water during power outages or pump failures. These well buckets are made of sturdy PVC with all stainless steel hardwear, so you never have to worry about any part rusting or corroding. Simply attach a rope to the eye hook at the top of the well bucket, and lower it into your well. The valve at the bottom of the bucket automatically opens, and the bucket is filled with water. Raise the bucket to the surface, place it in a 5 gal. bucket or other water container, and the valve will open and release the water. It is nominally 3 inches wide and just over 4 inches at the maximum. It will fit any 5 inch or larger drilled well. Holds about 1 1/4 gals.
