46rh Rebuild Manual Model

46RE, 47RE, 48RE – ATSG (Automatic Transmission Service Group) PDF. The 46RE, 47RE and 48RE family of transmissions by the Chrysler Group, are fitted behind a wide variety of engine sizes, including diesel, and across various vehicle lines. They are also available in 2WD and 4WD configurations. Beginning at the start of production for model year 2005, Dodge trucks equipped with the 5.9L diesel and 48RE transmission were equipped with an electronically controlled Transmission Throttle Valve Actuator (TTVA). This Actuator has replaced the previous Throttle Valve Cable and all associated linkage. A push-in Transmission Range Sensor was implemented in model year 2002 to replace the screw-in Park/Neutral switch.

46RH/46RE/47RH/47RE/48RE (A518 / A618) RWD 4 Speed A Pump Body 070 034 777 309 510 530 520 179 Stator 778 500 Pump 311 310 037 211. 022 Kickdown Band 555 Direct Drum 337 336 B 760 335 334 964 974 853 877 564 149 108 126 Forward Clutch 146 878. 232 233 894 582 Forward Planet 238 592 Forward Ring Gear C 191 927 192 926 925 Accum. Chrysler 46rh Repair Manual 46RH transmission repair manuals (46RE/47RH/A518/A618) 46RH transmission information about rebuild (46RE/47RH/A518/ A618) This generation of the automatic transmission 46RH has proven itself with the best hand. The legendary reliability is combined with the power and the ease of repair. 46RH transmission repair manuals. CHRSLER 46RE, 46RH, 47RE, 47RH ZIP IT ® PAT NUBE 46-47E-IP UIC UIE 1 3 4 5 2 5 ©2019 Sonnax Transmission Company, Inc. A Marmon/Berkshire Hathaway Company 46-47RHE-ZIPGuideA 02-11-19.

The 46RE, 47RE and 48RE transmissions are all four speed fully automatic units with an electronic governor. They are equipped with a lock-up clutch in the torque converter. First through third gear ranges are provided by the clutches, bands, low-roller clutch, and planetary gearsets in the transmission. Fourth gear is provided by the overdrive unit (rear section) that contains an overdrive clutch, OD/direct clutch, overrun roller clutch, and planetary gearset.

These units contain a front (direct) clutch, rear (forward) clutch, and OD/direct clutch which serve as the input driving components. They also contain a kickdown (front) band, low/reverse (rear) band, overrun clutch, and the overdrive clutch which serve as the holding components.

Applications A518 (46RE):

Dodge Ram pickup and vans 150/250/350 V8 and diesel engines (DGT)
Dodge Ramcharger SUV 1988-1993 5.2L & 5.9L V8
Jeep Grand Cherokee 1998 5.9L
Jeep Grand Cherokee 1993-1995 5.2 V8
1996 Dodge Dakota V8 (Also 98-03 Dakota 5.9L R/T)
1998-2003 Dodge Durango 5.9L V8 (4WD or 2WD)
1998–2003 Dodge Dakota R/T
1994-1995 Dodge Ram 2500/3500 V8
1995 Dodge Dakota 5.2l magnum v-8
X-1995 Dodge Ram Van 2500 5.2L Magnum V8

Applications A618 (47RE/48RE):

Dodge Ram pickups 2500/3500 ISB Diesel and iron V-10 (DGP)
Dodge Ram SRT-10 (DGP)f
1996-2002 (Also some early production 2003’s) Dodge Ram 2500/3500 Diesel/V10
1994-1995 Dodge Ram 2500/3500 Diesel/V10
2003-2004 Dodge Ram 2500/3500 ISB Diesel
2003-2004 Dodge Ram 2500/3500 HO ISB Diesel
2004-2007 Dodge Ram 2500/3500 600/610 Diesel
2004-2006 Dodge Ram SRT-10
